Motorized Welding Cross Slides 8" x 8" WCS-88M

Motorized Welding Cross Slides

Specifications:
• Travel: 7-7/8″ x 7-7/8″
• Slide Adjustment: Variable 0-8 i.p.m.
• Control: Joystick Pendant
• Load Capacity: 200 lbs. @ 4” Centre of Gravity
• Motors: 24 VDC
• Input Power: 115 VAC
• Dimensions (WxHxD): 19-1/4” x 19-1/4” x 6-3/4”
• Weight of Slides: 86 lbs.
• Weight of Slides & Controls: 98 lbs.
• Back of Slide Mount: 4 EA. M10 Pre-Drilled Holes
• Welding Head Mounting: 4 M10 – 1.5 Tapped Holes
• Driven Screw: 1″ Dia.
• Load Bearing Guide Rods: 1-1/8″

In stock
